Product Description:

Standard Features:

1. Vacuum Pump for bag pick up and opening.
2. Pouch feeding conveyor.
3. Integration in existing packaging line.
4. Completely manufactured in stainless steel for food industry.
5. Advanced PLC control system combined with 5.7″ Colorful touch screen control panel, can easily set and change packing parameters, display production data and self-diagnostic machine error can be viewed directly from the screen.
6. 20 sets of programs.
7. Fully pneumatic operating system, easy operation and maintenance.

Working Principle:

1. Bag Picking from infeed conveyor
2. Positioning Bag to the filling station
3. Open Bag
4. Product Filling (filling device is a piston pump)
5. Bag Closing and Sealing
6. Bag Outfeed Conveyor

Optional Dosing Device

1. Volumetric Cup Filler or Multi heads weigher (for granule)
2. INCLUDES Piston Pump (for liquid or cream)
3. Auger screw Filler (for powder)
4. Electrical Gear Pump (for liquid)

Pump Filler

2014 Techongda

Quantitative Filling Machine

Single Head Paste filler

Model:             C1wc

Air:      filling accuracy +-0.5%

1) Packaging material: Nylon/ PET laminate, PET/PET laminate, Nylon/Aluminum Foil/PET laminate, PET/Aluminum Foil laminate, PET/any heat seal material laminate

3) Speed: 0-7 pcs/min

4) Voltage: 220VAC, 1PH, 50/60Hz

5) Power: 1.5 KW

6) Machine weight: 660 lbs.

7) Machine size: 95.50”L x 28.00” W x 65.00” H
